Gold Cura Taper Conical Point Diamond Burs FG – TC Series, Pack of 5
In stock
Couldn't load pickup availability
In stock. Estimated delivery within 4–5 working days.
Quick Answer
Pointed taper-conical FG diamond burs for interproximal access, proximal reduction, narrow grooves and precise contouring. Choose one of five TC profiles; pack of 5 identical burs.
Direct answer: Gold Cura Taper Conical Diamond Burs FG are slender pointed or conical friction-grip burs for interproximal access, proximal contouring, narrow grooves, crown preparation and precise margin refinement. Choose TC-10, TC-11, TC-20, TC-21 or TC-26. Each order contains 5 identical burs of the selected code.
Taper Conical Diamond Burs: Key Facts
| Available codes | TC-10, TC-11, TC-20, TC-21 and TC-26 |
|---|---|
| Head shape | Tapered conical / pointed profile |
| Typical applications | Interproximal access, proximal reduction, IPR, narrow grooves, axial contouring and precise margin refinement |
| Shank | FG / friction grip |
| Pack size | 5 identical burs of the selected TC code |
What Is a Taper Conical Diamond Bur?
A taper conical bur narrows toward a pointed terminal area. It is useful where a broad flat or round end would obstruct access, particularly for interproximal surfaces, fine contouring and narrow preparation features. It should not be used to create a flat shoulder because its terminal geometry is pointed rather than flat.
When to Use Each TC Bur
TC codes represent different lengths and widths. Comparable catalogues describe TC-10 and TC-11 as longer pointed profiles and TC-20 and TC-21 as shorter alternatives. TC-26 is a slender precision option. Confirm the exact Gold Cura geometry and dimensions from the product image and supplied specification.
| Code | Relative profile | When to use it |
|---|---|---|
| TC-10 | Narrow long point | Conservative interproximal access, fine proximal contouring, narrow axial reduction and delicate margin work. |
| TC-11 | Broader long point | Routine proximal reduction, longer axial contouring and broader interproximal shaping than TC-10. |
| TC-20 | Narrow shorter point | Localised proximal access, short preparation walls, small grooves and restricted areas where a long head is unnecessary. |
| TC-21 | Medium shorter point | General short-profile contouring, moderate interproximal reduction and precise localised preparation. |
| TC-26 | Slender precision point | Very fine access, narrow line or groove development, delicate interproximal finishing and precise localised contouring. |
Simple selection rule: choose long TC-10 or TC-11 for extended side contact, short TC-20 or TC-21 for localised work, and TC-26 for the finest pointed access.
TC vs TF and TR Diamond Burs
| Code family | Terminal form | Typical selection |
|---|---|---|
| TC taper conical | Pointed | Interproximal access, fine contouring and narrow grooves |
| TF taper flat-end | Flat | Defined tapered walls and shoulder-style terminal form |
| TR taper round-end | Rounded | Chamfer-style margins and rounded internal transitions |
Frequently Asked Questions
What are taper conical diamond burs used for?
They are used for interproximal access, proximal reduction, narrow grooves, fine axial contouring and precise margin refinement.
Which TC burs have longer heads?
TC-10 and TC-11 are the longer profiles, with TC-11 relatively broader.
Which TC burs are shorter?
TC-20 and TC-21 are shorter profiles, with TC-21 relatively broader.
When should I use TC-26?
Use TC-26 for very fine pointed access and localised precision contouring.
Can TC burs create a flat shoulder?
They are not the preferred choice for a flat terminal shoulder because the head is conical and pointed. A TF or SF profile may be more appropriate.
Is this a mixed pack?
No. Each pack contains five identical burs of the selected TC code.
What are the exact dimensions?
Confirm the Gold Cura packaging or supplied technical specification.
Can these burs be sterilised and reused?
Follow the supplied processing, reuse and replacement instructions.
Related Gold Cura Dental Burs
- Tapered Fissure Diamond Burs
- Taper Round-End Diamond Burs
- Fine Finishing Diamond Burs
- Dental Burs & Bur Kits
Professional-use dental instrument. Confirm the actual profile, dimensions, grit, speed, cooling and processing instructions before use.
Browse related products: Dental Diamond Burs.
Need help selecting a bur? Use the Dental Diamond Bur Shapes Selection Guide to compare round, tapered, conical, finishing and coarse profiles.
Why Dentists Choose This Product
- Pointed taper-conical FG diamond burs for interproximal access, proximal reduction, narrow grooves and precise contouring. Choose one of five TC profiles; pack of 5 identical burs.
- Compatibility: Compatible with a suitable high-speed FG / friction-grip dental handpiece. The pointed profile is not the preferred choice for a flat shoulder; select TF or SF when that geometry is required.
- Package: 1 × pack containing 5 items as specified
